The Use of Asynchronous Counters Controlled ... - видео

The Use of Asynchronous Counters Controlled Frequency Divider Controlled frequency dividers are a type of dividers with output frequency determined by the control code. Controlled frequency dividers can be built on asynchronous counters. Let us consider for example a divider by 2n where n is a whole number. The 8-bit counter IE19 operates by input signal with clock speed fT. The output 8-input multiplexer KP7 transmits one of the 7 bits of the counter or the input signal to the circ...
Источник видео: RuTube.ru (Технологии и интернет)
